Thanks. Updated the table.

You think I'm missing anything else that would be helpful to someone who's new to relays or looking for a recommended product?

I use this Bosch high current relay for fuel injection conversions on early Fords. I basically use the factory ignition switch to turn it on and off. Then the relay powers up essentially a stand alone system for the fuel injected motor. This allows use of the early switch that cannot handle a fuel injection systems electrical demands. I have used it on 1st gen broncos, comets, etc. I don’t think there is much use on a Jeep but could be used for overland type rig.

https://www.summitracing.com/parts/...MI0OS35eu_gwMV-hGtBh0LSgKtEAQYCSABEgJ2ifD_BwE



[SSTJ]

Does the "20/40" amp rating on this SPDT mean that each one of the two 87 pins can handle up to 20 amps? So 40 "total", even though only 20 should be used?

https://www.amazon.com/gp/product/B004NIKXSY/?tag=wranglerorg-20



[SSTJ]

I use this Bosch high current relay for fuel injection conversions on early Fords. I basically use the factory ignition switch to turn it on and off. Then the relay powers up essentially a stand alone system for the fuel injected motor. This allows use of the early switch that cannot handle a fuel injection systems electrical demands. I have used it on 1st gen broncos, comets, etc. I don’t think there is much use on a Jeep but could be used for overland type rig.

[URL]https://www.summitracing.com/p...MI0OS35eu_gwMV-hGtBh0LSgKtEAQYCSABEgJ2ifD_BwE[/URL]

Adding it now.



[707kevin]

Does the "20/40" amp rating on this SPDT mean that each one of the two 87 pins can handle up to 20 amps? So 40 "total", even though only 20 should be used?

https://www.amazon.com/gp/product/B004NIKXSY/?tag=wranglerorg-20

The dual ratings are used when NC/NO ratings are different.
